All Lights On® for 2016 - 2023 Toyota Tacoma

Brighten up your driving experience with this simple upgrade inside your underhood relay box. Simply install the All Lights On module to allow your high-beams and fog lamps to simultaneously illuminate the road ahead. Once installed the All Lights On module will keep your fog lamps on when you turn ON your high-beams. When the high-beams are NOT turned on your low-beams and fog lights will function normally.

Installation

1. Open the hood and remove the relay panel cover.
2. Remove the relays labeled: FOG FR and DIMMER
3. Insert the relays through the All Lights On boards with the wire connection facing towards the top of the relay.  The board will make a firm connection with the relay.
4. Reinstall the two relays back into their original location and install the relay panel cover.

Operation

MY2016-2023 Tacoma: High beams, low beams, and fog lights on when high beams are enabled.  The fog lights will not be enabled when the auto-high beam feature is activated.  For full functionality, auto-high beams should be deactivated.

Application

Fits 2016-2023 Toyota Tacoma with factory installed fog lamps.

See Instructions tab on this page for a link to the detailed installated instructions.

* Protected under US Trademark Reg. No. 6068463, 6099979, US Copyright Reg No. TXu 2-413-681, and US Patents Pending
